Garmin GPSMAP 1242xsv GN+ Chartplotter/Fishfinder With Transducer

12-Inch Display with Garmin Navionics+ Charts and All-In-One Transducer

A bright, 12.1” keyed display and packaged with an all-in-one transom mount transducer, the GPSMAP 1242xsv with GN+ Charts and GT52HW provides detailed chart coverage for coastal and lake waters, and includes CHIRP sonar with ClearVu and SideVu scanning capabilities!

Display:

A crisp, clear 12.1” WXGA display, the GPSMAP 1242xsv offers a 1280×800 resolution and is waterproof to IPX7 standards. Packaged with both bail and flush mount options, the GPSMAP is equipped with 2SD card slots and internal memory for up to 5,000 waypoints, 50,000 track points, 50 saved tracks and 100 routes. This powerhouse GPS/Fishfinder is a top contender for those looking for a solid, rugged, and reliable display!

Sonar:

Built with an internal 1kW Single Channel CHIRP sonar and packaged with a GT52HW Transom Mount transducer, the 1242xsv is ready to go right out of the box. High Wide CHIRP Sonar provides high frequency CHIRP Sonar (150-240kHz) with a 250W power rating reaching depths of 800’ and CHIRP ClearVu and SideVu sonar (455/800 kHz) with a power rating of 350W per element reaching depths of 500’ left to right and 500’ down. Fully compatible with Panoptix All seeing sonar, as well as enhanced sonar modules like the Garmin GSD’s (sold separately) for dual channel chirp or higher output power (2-3kw) your sonar options really are endless when it comes to the GPSMAP 1242xsv.

Charting:

Each GPSMAP 1242xsv GN+ comes preloaded with Garmin Navionics+ detail for the Coastal and Inland waters throughout the US including Auto Guidance+ technology. Offering detail-rich charts of coastal waters, lakes and rivers, the built-in charting now includes auto-routing solutions giving you a suggested path to follow thru channels, inlets, marina entrances and more. (*please note, AutoGuidance is for planning purposes only and should not replace safe navigation) Preloaded Garmin Navionics Charts include detailed coverage of the entire U.S. coasts, lakes, rivers and inland waterways, plus Alaska and Hawaii. Canada coverage of coastal British Columbia, the Great Lakes, the St. Lawrence Seaway, New Brunswick and Nova Scotia. Coverage includes Bermuda, the Bahamas, Baja California, the Gulf of California, Johnston Atoll and Palmyra Atoll/Kingman Reef.

Network Support:

Fully Networkable, the GPSMAP 1242xsv offers two network ports for the addition of multiple displays, Radar, Sonar, SiruisXM and more. If adding more than two network components, please note that a GMS10 port expander will be required (sold separately). In addition, the GPSMAP 1242xsv supports both NMEA0183 and NMEA2000 (NMEA2000 starter kit required, sold separately) for connection to VHF, AIS and other NMEA communication devices.

Premium Charting Options:

The Garmin GPSMAP GN+ displays are compatible with Garmin Navionics Vision+ charts, Garmin’s premier chart offering. Garmin Navionics Vision+ charts include both coastal and lake coverage within the region of your choice. Data is sourced from Garmin and Navionics in order to provide you with exceptional detail. Regions are larger than previous charting from Garmin and provide High Resolution Relief Shading, Auto Guidance+ routing, High Resolution Satellite Imagery, Sonar Imagery, Aerial Photography, SideScan Images and 1-year of free daily updates via the Garmin ActiveCaptain app! Garmin Navionics Vision+ charts require premium content to be downloaded post purchase via the ActiveCaptain app with a compatible smartphone or tablet. All premium chart options are available in the region of your choice and sold separately.

For a top choice combination that is ready to go out of the box the 1242xsv GPS/Fishfinder with keyed display is a top choice!

*Please note, This display has a single 12 Pin Transducer Port. Garmin 12 Pin orange connectors do not support speed thru water via a speed wheel. This display will provide speed over ground via GPS. Speed thru water can be achieved by adding a NMEA Smart sensor, sold separately.

The Garmin GPSMAP 1242xsv GN+ is a multifunction display with preloaded Garmin Navionics+ charts featuring coastal and inland chart content of the US and Canada with Auto Guidance+ technology and 1-year of free daily updates via the ActiveCaptain app. The included GT52HW transducer provides CHIRP Traditional Sonar and CHIRP ClearVu/SideVu. View sonar, charts and network accessories on the sunlight readable 12-inch keypad-controlled display!
